RAT3

RAT3

product line: Spiral

Radiator is suitable for connection to a low-temperature system in a vertical version only!

Material: Steel tubes 32, 57, 76, 89 or 108 mm; steel belts, width 0.8 mm
Max. operating temperature: 120 °C
Working overpressure: 1 MPa
Testing overpressure: 1.3 MPa
Connection threads: 2 × G1/2"
Standard colour: RAL 9016, white

Lengths - horizontal models: between 500 mm and 6 000 mm
Lengths - vertical models: between 500 mm and 2 500 mm

Horizontal models: floor and wall mounting
Vertical models: wall mounting

Contacts contact us
lenght [mm]
heating at a temp. gradient of 75/65/20 °C [W]
32x92mm 57x137mm 76x156mm 89x169mm 108x188mm
500 299 398 443 471 514
1000 640 849 946 1006 1098
1500 997 1324 1475 1568 1712
2000 1366 1814 2020 2148 2346
2500 1745 2317 2580 2743 2995
3000 2130 2828 3150 3349 3657
4000 2919 3876 4316 4589 5011
5000 3726 4948 5510 5860 6398
6000 4550 6041 6728 7155 7811
gallery colors download
Anthracite - metallic - S02 (61) Anthracite - metallic S02 (61)
Black - RAL 9005 (19) Black RAL 9005 (19)
Copper - metallic - S03 (62) Copper - metallic S03 (62)
Brass - metallic - S19 (83) Brass - metallic S19 (83)
Sandstone - texture - S13 (72) Sandstone - texture S13 (72)
Ivory - texture - S08 (67) Ivory - texture S08 (67)
Snow (traffic) white - RAL 9016 (01) Snow (traffic) white RAL 9016 (01)
Snow-white - texture - S09 (68) Snow-white - texture S09 (68)
Silver - metallic - S05 (64) Silver - metallic S05 (64)
Aquamarine - metallic - S29 (23) Aquamarine - metallic S29 (23)
Black velvet - matt - S40 (51) Black velvet - matt S40 (51)
Antibacterial white - S41 (88) Antibacterial white S41 (88)
Antique gold - metallic - S36 (48) Antique gold - metallic S36 (48)
Transparent paint - S20 (84) Transparent paint S20 (84)
Lava ash - texture - S33 (27) Lava ash - texture S33 (27)
Sapphire - S30 (24) Sapphire S30 (24)
Cinnamon - texture - S35 (29) Cinnamon - texture S35 (29)
Gold olive - texture - S28 (22) Gold olive - texture S28 (22)
Champagne - metallic - S31 (25) Champagne - metallic S31 (25)
Light pink - RAL3015 MAT (K2) Light pink RAL3015 MAT (K2)
Window grey - RAL7040 MAT (K3) Window grey RAL7040 MAT (K3)
Claret violet - RAL4004 MAT (K4) Claret violet RAL4004 MAT (K4)
Light green - RAL6027 MAT (K5) Light green RAL6027 MAT (K5)
Pastel blue - RAL5024 MAT (K6) Pastel blue RAL5024 MAT (K6)
Pastel green - RAL6019 MAT (K72) Pastel green RAL6019 MAT (K72)
Grey beige - RAL1019 MAT (K8) Grey beige RAL1019 MAT (K8)
White matt - RAL 9016MAT (05) White matt RAL 9016MAT (05)
Ivory - RAL 9001MAT (K9) Ivory RAL 9001MAT (K9)
Jasmine - RAL1015 (12) Jasmine RAL1015 (12)
Fir green - RAL 6009 (43) Fir green RAL 6009 (43)
Window grey - RAL 7040 (31) Window grey RAL 7040 (31)
Pearl black - S22 (85) Pearl black S22 (85)
Pearl grey - S23 (86) Pearl grey S23 (86)
Light gold - S75 (L1) Light gold S75 (L1)
Beige grey - RAL 7006MAT (C7) Beige grey RAL 7006MAT (C7)
Dark brown matt - S59 (H4) Dark brown matt S59 (H4)
Brown quartz - J9 (S66) Brown quartz J9 (S66)
